                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Regenerative Heat Exchanger Evaporator Coil, Small Evaporator Coil, Refrigerator Evaporator Coil


Model No.:	yelken-11	İlke:	Rejeneratif Isı Eşanjörü
Stil:	Plaka tipi	Malzeme:	Paslanmaz çelik
Bakır boru çapı:	Φ7, φ7.94, φ9.52	Tüp tipi:	İç oluklu veya pürüzsüz tüp
Alüminyum folyo tipi:	hidrofilik veya çıplak	Yüzgeç tipi:	Panjur Fin, Düz Fin, Oluklu Fin
Yüzgeç perdesi:	Ø7 1.1 ~ 1.8mm, Ø7.94 1.4 ~ 2.0mm, Ø9.52 1.4 ~ 2.3mm	delik aralığı:	20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm
Yüzgeç kalınlığı:	0.095 ~ 0.2mm	Fin alanı:	1.4 ~ 2.3mm
Tüp malzemesi:	Bakır, alüminyum	Üretim kapasitesi:	50000 adet/Yıl
HS kodu:	8419500090

Model No.:	yelken-11
İlke:	Rejeneratif Isı Eşanjörü
Stil:	Plaka tipi
Malzeme:	Paslanmaz çelik
Bakır boru çapı:	Φ7, φ7.94, φ9.52
Tüp tipi:	İç oluklu veya pürüzsüz tüp
Alüminyum folyo tipi:	hidrofilik veya çıplak
Yüzgeç tipi:	Panjur Fin, Düz Fin, Oluklu Fin
Yüzgeç perdesi:	Ø7 1.1 ~ 1.8mm, Ø7.94 1.4 ~ 2.0mm, Ø9.52 1.4 ~ 2.3mm
delik aralığı:	20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm
Yüzgeç kalınlığı:	0.095 ~ 0.2mm
Fin alanı:	1.4 ~ 2.3mm
Tüp malzemesi:	Bakır, alüminyum
Üretim kapasitesi:	50000 adet/Yıl
HS kodu:	8419500090

Small Refrigerator Stainless Steel Evaporator Coil with Regenerative Heat Exchanger

Factory Price Refrigerator Small Condenser Stainless Steel Evaporator Coil

Product Specifications

Material: copper, aluminum, galvanized plate
Copper pipe: diameter Φ7, Φ7.94, Φ9.52, inner grooved or smooth tube
Aluminum foil: hydrophilic or bare
Fin type: louver fin, flat fin, corrugated fin
Pitch of fins: Ø7 1.1~1.8mm, Ø7.94 1.4~2.0mm, Ø9.52 1.4~2.3mm
Pitch of holes and pitch of rows: 20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm equilateral triangle arrangement

Evaporator Specifications

NO	Tube Diameter(mm)	Distance of hole/row(mm)	Fin Style	Fin Space(mm)
1	Φ7	21*12.7	Louvered fin, Plain fin, Sine wave fin	1.4~2.0
2	Φ7	21*18.9	Sine wave fin, Corrugated fin	1.3~1.9
3	Φ7	25*21.65	Louvered fin	1.5~3.8
4	Φ9.52	25.4*22	Louvered fin, Sine wave fin	1.6~6.35
5	Φ9.52	25.4*22	Louverd fin, Plain fin, Sine wave fin	1.6~3.2
6	Φ9.52	25*19	Louverd fin, Plain fin, Sine wave fin	1.4~3.2
7	Φ9.52	25*21.65	Louvered fin, V ripple fin	2.0~3.8
8	Φ9.52	25*25	Plain fin	1.6~3.2
9	Φ9.52	25*21.65	Plain fin	2.0~6.0
10	Φ9.52	25.4*22	Louvered fin, Plain fin, Sine wave fin	1.6~6.35
11	Φ9.52	31.75*27.5	Louvered fin, Plain fin, Sine wave fin	1.6~6.35
12	Φ12.7	31.75*27.5	Plain fin, Sine wave fin, V ripple fin	1.8~6.0
13	Φ12.7	31.75*27.5	Louvered fin, Plain fin, Sine wave fin, V ripple fin	1.7~2.2
14	Φ12.7	31.75*27.5	Corrugated fin	1.6~2.9
15	Φ15.88	38.1*33	Plain fin, Sine wave fin, V ripple fin	2~4

Product Series Comparison

Specification	Series 1	Series 2	Series 3	Series 4
Tube Diameter	Φ9.52	Φ9.52	Φ7	Φ7.94
Hole Space(mm)	25	25.4	20.5	22
Row Space(mm)	21.65	22	12.7	19.05
Tube Material	Copper, Aluminum	Copper, Aluminum	Copper, Aluminum	Copper, Aluminum
Type of Tube	Smooth Tube, Inner Grooved Tube	Smooth Tube, Inner Grooved Tube	Smooth Tube, Inner Grooved Tube	Smooth Tube, Inner Grooved Tube
Fin Surface	Louver Fin, Corrugated Fin	Flat Fin, Louver Fin, Corrugated Fin	Flat Fin, Louver Fin	Louver Fin
Fin Type	Hydrophilic Foil, Bare Foil, Copper Foil	Hydrophilic Foil, Bare Foil	Hydrophilic Foil, Bare Foil, Golden Foil	Hydrophilic Foil, Bare Foil, Golden Foil
Fin Thickness(mm)	0.095~0.2	0.095~0.2	0.095~0.2	0.095~0.2
Fin Space(mm)	1.4~2.3	1.4~2.3	1.1~1.8	1.4~2.0
